Heart Plus Aed

AUTOMATED EXTERNAL DEFIBRILLATOR

Description

HeartPlus NT-180 is a compact, portable device that analyses the heart’s rhythm and delivers a defibrillation shock to re-establish the normal heart rhythm. HeartPlus NT -180 guides the user through each step of the defibrillation process by providing voice/ visual prompts.

HeartPlus NT -180 of Nanoomtech Co., Ltd provides Uni-Pads which can be used for both adults and child and two types of cartridges, integrated-type or separated-type.

TECHNICAL DETAILS:

Energy : 180J(Adult), 50J(Child)
Shock Charge Time : Approx. 13 Seconds
Lead 2
Analysis Time : Less than 11 Secons
ECG 1,000 instance of 5 seconds recordings
Ambient Noise : Total 60 Minutes (4 instances of 15 minute cycles)
Self-Test: Times & Result of 3,000 events

Product Highlights

Defibrillator

Defibrillator Series	HeartPlus NT-180
Set Configuration	Defibrillator, battery pack, sealed electrode pads, HeartPlus User Guide, Protective Carrying Case, “NT-MPR” CD-ROM USB cable
Waveform	Truncated Exponential Biphasic
Energy	180J (adult, impedance 50?) / 50J (pediatric, impedance 50?)
ShockChargelimeI	Less than 13 seconds
Shock Method	Manual button (flashes when ready)
Mode Conversion	Adult/Child separate power buttons Child Mode delivers 50J Pediatric shock for patients weighing less than 25kg, approximately 12 months to 8 years old)

Physical

Dimensions	7.1cm (H) x29.3cm (W) x29.1cm (D)
Weight	1.9kg (including battery pack and electrode pad)

Environmenta

Water resistance	IPX2 based on IEC 60529
Temperature	Operating : 0? to 40? / Storage : -20? to 60?
Humidity (operating/storage)	10% to 95% Relative Humidity, Non-Condensing
Altitude (operating/storage)	0 to 2000 meters
Drop test	1M

ECG

ECG Record	LEAD II
Analysis Overview	Patient evaluated to determine whether ECG rhythm represents shockable or non-shockable state. Shockable rhythms are ventricular fibrillation (VF) and ventricular tachycardia (VT).
Analysis time	Less than 11 seconds (Read: 5 seconds ± 2 seconds, Analyze: within 4 seconds)

Audio/ Visual instruction

After device is powered on, step-by-step voice instructions guide first responder through resuscitation procedure, which includes pads placement, hands offtimes (analysis and shock process), and CPR

CPR instruction prompts user to commence cardiopulmonary resuscitation, while flashing metronome light sets pace at 100 compressions per minute for 30 compressions with brief pause for 2 mouth-to-mouth breaths (5 repetitions), in accordance with American Heart Association 2010 guidelines.

Data

Storeda data	ECG recordings, operation information (whether shock delivered or not), ambient noise, self-diagnostics history
Memory capacity	ECG: 1,000 instances of 5 seconds recordings Ambient Noise: Total 60 minutes (4 instances of 15 minute cycles) Self-Test: Times & results of 3,000 events
Storage type	Internal Memory
Access/search	“NT-MPR” App (for PC) via USB connection

self-diagnostics Test

Daily self-diagnostics tests ensure that circuits for measuring patient impedance, control circuit internal discharge of electric energy, and control circuit for charge/discharge of electric energy are functioning

A voice prompt stating “Equipment check is needed” continuously in the event self-diagnostics check fails.

Upon completion of daily self-diagnostics test, results are automatically stored within device’s internal memory.

Battery Check

When battery reserve is at acceptable level to provide sufficient electric charges and there are no problems with circuitry detected during self check, there Status LEDs above the power button blink in order from left to right during self check.
All three Status LEDs blink at the same time continuously with low or critical battery voice prompts when battery is at low or critical levels (low: shock possible, critical: shock not possible).
Battery Status Audible Warnings	Low: Voice prompt states “Battery’s voltage is low, check battery” Critical: Voice prompt states “Change cartridge”

Electrode pads

Shelf Life	Two (2) years, for one-time use only
Conductive Gel	PE foam, Hydrogel
Conductive Element	AgCl (Silver Chloride)
Cable Length	2.1m (+1%)
Applicable Ages	All ages (12 months & older)
Sealing	Airtight
Size	125mm x 95mm
Pads Placement	Anterior-lateral (visual details on pads)

Battery Cartridge

Type	Non-rechargeable lithium (LiMn02)
Capacity	180 shocks @ 25? ,130 shocks @ 0?
Voltage	DC 21V& DC V / 1,400mAH
Standby Mode Life	Recommended five (5) years @ 25?
Dimensions	3.3cm (H) x 15.0cm (W) x 11.0cm (D)
